大家参加A-level考试,不少同学选择参加考试科目的时候,会选择物理课程,但是物理课程并不是很简单,特别是物理实验的部分,那么今天小编就为大家带来了ALevel物理大纲要求学生掌握的18个实验!
1. Use of, for example, lightgates and air track to investigate momentum and change in momentum
Investigateand apply the principle of conservation of linear momentum to problems in onedimension
Investigateand relate net force to rate of change of momentum in situations where mass isconstant (Newton’s second law of motion)
2. Investigate the effect of m,v and r of orbit on centripetal force
Usethe expression for centripetal force F = ma = mv2/r and hence derive and usethe expressions for centripetal acceleration a = v2/r and a = rω2.
Electric field
3. Demonstration of electriclines of force between electrodes
Drawand interpret diagrams using lines of force to describe radial and uniformelectric fields qualitatively
4. Use electronic balance tomeasure the force between two charges
Usethe expression F = kQ1Q2/r2, where k = 1/4πε0and derive and use the expressionE= kQ/r2 for the electric field due to a point charge
5. Use a Coulometer to measurecharge stored
Investigateand use the expression C = Q/V
6. Investigate energy stored bydischarging through series/parallel combination of light bulbs
Recogniseand use the expression W = ½ QV for the energy stored by a capacitor, derivethe expression from the area under a graph of potential difference againstcharge stored, and derive and use related expressions, for example, W = ½ CV2
7. Use of data logger to obtain I-t graph
Recogniseand use the expression Q = Q0 e-t/RC and derive and userelated expressions, for exponential discharge in RC circuits, for example, I =Io e-t/RC
Magnetic field
8. Electronic balance to measureeffect of I and l on force
Investigate,recognise and use the expressionF = BIl sin θ and apply Fleming’s left hand rule to currents
9. Deflect electron beams with a magnetic field
Recogniseand use the expression F= Bqv sin θ and apply Fleming’s left hand rule to charges
10. Use a data logger to plot V against t as a magnet falls through a coil of wire
Investigateand explain qualitatively the factors affecting the emf induced in a coil whenthere is relative motion between the coil and a permanent magnet and when thereis a change of current in a primary coil linked with it
Thermal energy
11. Measure specific heatcapacity of a solid and a liquid using, for example, temperature sensor anddata logger
Investigate,recognise and use the expression ΔE= mcΔθ
12. Temperature and pressuresensors to investigate relationship between p and T
Experimentalinvestigation of relationship between p and V
Usethe expression pV= NkT asthe equation of state for an ideal gas
Nuclear decay
13. Measure background count rate
Showan awareness of the existence and origin of background radiation, past andpresent
14. Investigate the absorption ofradiation by paper, aluminium and lead (radiation penetration simulationsoftware is a viable alternative)
Investigateand recognise nuclear radiations (alpha, beta and gamma) from their penetratingpower and ionising ability
15. Measure the activity of aradioactive source Simulation of radioactive decay using, for example, dice
Determinethe half lives of radioactive isotopes graphically and recognise and use theexpressions for radioactive decay:dN/dt=-λN, λ= ln 2/t½ and N= N0 e-λt
Oscillations
16. Use a motion sensor togenerate graphs of SHM
Obtaina displacement – time graph for an oscillating object and recognise that thegradient at a point gives the velocity at that point
17. Use, for example, vibrationgenerator to investigate forced oscillations
Investigateand recall how the amplitude of a forced oscillation changes at and around thenatural frequency of a system and describe, qualitatively, how damping affectsresonance
18. Use, for example, vibrationgenerator to investigate damped oscillations
Explainhow damping and the plastic deformation of ductile materials reduce theamplitude of oscillation
以上就是ALevel物理大纲要求学生掌握的18个实验,希望大家根据自身情况制定合理的复习计划,同时小编提醒大家,千万不要忽视ALevel的备考!如果想要了解更多关于英国alevel官网、新加坡a水准官网的信息,可以在线咨询我们或添加客服微信kewo11!
